screen
|
5.7” 640 x 480 diagonal TFT LCD module |
Touch panel |
5-wire resistive touch screen |
Teclado |
Membrane keypad |
Backlighting |
LED backlighting, adjustable brightness |
|
Enlarged box: 1.5… 2.0 kg; Flat box: 1.5kg |
Dimensions |
-
-
-
- Enlarged box: 200 x 230 x 70 mm (d x w x h)
-
- Flat box: 200 x 230 x 57 mm (d x w x h)
|
Battery type |
Lithium-ion polymer, rechargeable, 4200 mAh, 11.1V |
Charging time |
Aprox. 4 horas |
Charger power supply |
100 … 240V CA, 50-60 Hz |
Battery life |
10 … 16 horas |
Operating temperature |
-10 … 45ºC |
Operating temperature during battery charging |
0 … 30ºC |
Storage temperature |
-20 … 60ºC |
Valid specifications |
0… 45°C, unless otherwise indicated |
Humidity
|
0… 80 % non-condensing HR |
Preheating time |
Specifications valid after 5 minutes of preheating |
Maximum input voltage |
30 V AC, 60 V DC, 60 V DC |
Screen refresh |
3 readings/second |
Security |
Directiva 2006/95/EC, EN 61010-1:2001 |
Electro-magnetic compatibility (EMC) |
Directiva 2004/108/EC, EN 61326-1:2006 |
IP rating |
IP65 |
Fall |
IEC 60068-2-32. 1 m |
Vibration |
IEC 60068-2-64. Random, 2 g, 5… 500Hz |
Maximum altitude |
3000 m |
